| Central wavelength (nm)a, b | OSICS SLD 1300: 1320; OSICS SLD 1550: 1540 |
| Spectral widthc | –3 dB (FWHM): 50 nm; –10 dB: 80 nm; –20 dB: 100 nm; –30 dB: 125 nm |
| Output power (mW) | High: 10; Low: 5 |
| Power stability over temperature range (dB)d | ±0.1 |
| Power stability at constant temperature (dB) | ±0.01 |
| Optical fiber | SMF |
| Optical interface | FC/APC connector |
| a. Typical. b. ±20 nm. c. Guaranteed at output power = 10 mW. d. Operating temperature range 15 °C to 35 °C. | |
| High output power | 10 dBm |
| Excellent power stability | The module’s monitoring photodiode provides power for real-time feedback, delivering extremely stable output power and eliminating the need for frequent referencing during component testing. |
| Isolation | The module features an isolator to maintain power stability even in the presence of back reflections from a test setup. |
| Broad wavelength range | ~150 nm range with a spectral power density higher than –40 dBm/nm. |
