| Wavelength range (C-band) | 1527.99-1567.95 nm (191.2-196.2 THz) |
| ITU channels | ITU-T G694.1 channels 12-62 |
| Channel spacing | DWDM 100 GHz |
| Dynamic range per channel (dBm) | 10 to −40 |
| Maximum total safe power (dBm) | 20 |
| Absolute power uncertainty (dB) (typical) | 1 |
| ORL (dB) | > 35 |
| Measurement time (s) | < 3 |
| Built-in power meter specifications (GeX) (optional) | |
| Calibrated wavelengths (nm) | 850, 1300, 1310, 1490, 1550, 1625, 1650 |
| Power range (dBm) | 27 to −50 |
| Uncertainty (%) | ±5 % ± 10 nW |
| Display resolution (dB) | 0.01 = max to −40 dBm 0.1 = −40 dBm to −50 dBm |
| Automatic offset nulling range | Max power to −30 dBm |
| Tone detection (Hz) | 270/330/1000/2000 |
| Technical specifications (for MAX-5205 version only) | |
| Display | 7-in (178-mm) outdoor-enhanced touchscreen, 800 x 480 TFT |
| Interfaces | Two USB 2.0 ports RJ45 LAN 10/100 Mbit/s |
| Storage | 2 GB internal memory (20 000 OTDR traces, typical) |
| Batteries | Rechargeable lithium-polymer battery 8 hours of operation as per Telcordia (Bellcore) TR-NWT-001138 |
| Power supply | Power supply AC/DC adapter, input 100-240 VAC, 50-60 Hz |
| Size (H x W x D) | 166 mm x 200 mm x 68 mm (6 9/16 in x 7 7/8 in x 2 3/4 in) |
| Weight (with battery) | 1.5 kg (3.3 lb) |
| Temperature | Operating: 0 °C to 40 °C (32 °F to 104 °F) Storage: −40 °C to 70 °C (−40 °F to 158 °F) |
| Relative humidity | 0 % to 95 % noncondensing |
| Visual fault locator (VFL) (optional) | Laser, 650 nm ± 10 nm CW/Modulate 1 Hz Typical Pout in 62.5/125 µm: > −1.5 dBm (0.7 mW) Laser safety: Class 2 |
