| Power meter specifications(a) | |
| Detector type | GeX |
| Uncertainty(b) | ±(5 % + 10 nW) |
| Measurement range (dBm) | 25 to −50(c) |
| Wavelengths range (nm) | 850, 1300, 1310, 1490, 1550, 1577, 1625, 1650 |
| Tone detection (Hz) | 270/330/1000/2000 |
| Source specifications(a) | |
| Output power (dBm)(c) | SM1 (1310 nm/1550 nm) : 2.5 SM3 (1310 nm/1550 nm/1625 nm) : 1 / −1 / −5 SM4 (1310 nm/1490 nm/1550 nm) : 1 / −5 / −1 |
| Output power stability (dB) | ±0.05 over 8 hours |
| ORL meter(a,g) | All single mode wavelengths |
| ORL range (APC/UPC link) (dB)(c,h,i) | 65/55 |
| ORL uncertainty (dB)(c,h,j) | ±0.5 |
| Resolution (dB) | 0.01 |
| FasTesT™ specifications(a) | |
| Testing speed(c) | FasTesT™ Simplex : 3 seconds (two wavelengths, bidirectional, automated, IL + fiber length) FasTesT™ Simplex : 6 seconds (three wavelengths, bidirectional, automated, IL + ORL + fiber length) |
| Wavelengths (nm)(c) | Singlemode (laser) : 1310 ± 20; 1490 ± 10; 1550 ± 20; 1625 ± 10 |
| Loss range (dB)(d) | Singlemode simplex : 45 |
| Length measurement range (km)(e) | Singlemode : 200 |
| Length measurement uncertainty(c) | Simplex : ±(1 m + 0.5 % × length) |
| ORL measurement range (dB)(c,f) | 50 |
| ORL measurement uncertainty (dB)(c,f,g) | ±1 |
| FasTesT™ mode | Simplex |
| Visual fault locator (VFL) (optional) | |
| Laser | 650 nm ± 10 nm |
| Mode | CW/Modulate 1 Hz |
| Typical Pout in 62.5/125 µm | > −1.5 dBm (0.7 mW) |
| Laser safety | Class 2 |
| a. All specifications valid at 23 °C ± 1 °C and 1550 nm, on batteries and after 15 minutes of warm up, unless otherwise specified. b. Uncertainty is valid at calibration conditions. c. Typical. d. Typical value, at 1550 nm for singlemode. e. At 1550 nm for singlemode. f. ORL measurement available on MaxTester 945 singlemode wavelengths only. g. No discrete reflectance greater than −65 dB. Up to 45 dB. h. After a manual reference and zero. Measurement made with 2 m reference patchcord with SC/APC connectors (all discrete reflectances ≤ −65 dB). i. After a manual reference and zero. Measurement made with 2 m reference patchcord which has one SC/UPC connector on the fiber under test side (all discrete reflectances ≤ −55 dB). j. Up to 45 dB. | |
| Temperature | Operating : −10 °C to 50 °C (14 °F to 122 °F) Storage : −30 °C to 70 °C (−22 °F to 158 °F)(a) |
| Relative humidity | 0 % to 95 % non-condensing |
| Display | 7-in (178-mm) outdoor-enhanced touchscreen, 800 × 480 TFT |
| Size (H × W × D) | 166 mm × 200 mm × 68 mm (6 9/16 in × 7 7/8 in × 2 ¾ in) |
| Weight (with battery) | 1.5 kg (3.3 lb) |
| Interfaces | Two USB 2.0 ports RJ45 LAN 10/100 Mbit/s Optional Wi-Fi/Bluetooth |
| Storage | 6 GB internal memory (150 000 test results, typical) |
| Battery(b) | Rechargeable lithium-polymer battery 12 hours of operation |
| Power supply | AC/DC adapter, input 100–240 VAC, 50–60 Hz |
| Warranty (year) | 1 |
| Calibration interval (years) | 3 |
| a. −20 °C to 60 °C (−4 °F to 140 °F) with the battery pack. b. Typical. | |
