| Transport and datacom module | FTBx-88260: 10M, 100M, 1G, 2.5G, 5G, 10G, 25G, 40G, 50G and 100G testing with swappable transceiver interfaces |
| OTS slots | The FTBx-88260 offers two OTS slots (A and B) that can each house any of the options SFP28, QSFP28, CFP4 or SYNC |
| SFP28 supported interfaces | SFP, SFP+, tunable SFP+, SFP28, copper SFP, SFP+ and bidirectional SFP |
| SFP28 features | 10M to 25G data rates; FC 1X to FC 32X data rates; Dual-port capability |
| SFP28 number of test ports | 2 |
| QSFP28 supported interfaces | QSFP+, QSFP28 |
| QSFP28 features | 25G / 40G / 50G / 100G data rates; Dual-port capability; AOC cables |
| QSFP28 number of test ports | 2 |
| CFP4 supported interfaces | CFP4, SMA (REF OUT) |
| CFP4 features | 100G data rate; Ref out for eye diagram analysis; Dual-port offered with extra OTS |
| CFP4 number of test ports | 1 |
| SYNC supported interfaces | SMA(a), SMB (EXT CLK and 1PPS) |
| SYNC features | Built-in GNSS/GPS; Ideal solution for one-way delay; Ready for next-gen timing applications |
| SYNC number of test ports | 1 |
| Physical interfaces RJ45 | Available on FTBx-8870 and FTBx-8880 |
| Physical interfaces RJ48C | Available on FTBx-8870 and FTBx-8880 |
| Physical interfaces BNC | Available on FTBx-8870 and FTBx-8880 |
| Physical interfaces Bantam | Available on FTBx-8870 and FTBx-8880 |
| Physical interfaces SFP/SFP+ | Available on FTBx-8870 and FTBx-8880 |
| a. For more information, please contact EXFO. b. With 1 PPS as test port c. BNC connector for input clock only. d. Supports tunable SFP+ and copper SFP+. | |
| Detailed compliance testing | IEEE 802.3 - 2022 standard; CFP MSA CFP4 Hardware Specification Revision 1.1 18 Mar 2015; CFP MSA Management Interface Specification Version 2.4 (R06b); ITU-T G.709, G.798 and G.872 |
| Multi-interface support | Pluggable, MSA-compliant QSFP+ transceivers; Pluggable, MSA-compliant CFP4 and QSFP28 transceivers; Pluggable, MSA-compliant SFP28 optical transceiver; External timing reference (DS1/E1/2 MHz/10 MHz); Low-speed and high-speed reference clock output for eye diagram measurements; SRBIDI support; Active optical cable support; Single lambda support QSFP28 (DR/FR1/LR1); Tunable SFP+ and complete ITU-T grid with 100 GHz and 50 GHz spacing |
| PRBS patterns per lane | Allows users to configure different PRBS patterns on different CAUI-4/XLAUI lanes in 40G/100G, and on physical lanes in OTU3/OTU4 unframed configurations; typically used to identify crosstalk issues when looking at the eye diagram |
| Per-wavelength power measurement | Allows users to measure the received optical power per wavelength CFP4 and QSFP+/QSFP28 transceivers |
| Remote access | Supported via EXFO Remote ToolBox, EXFO Multilink, VNC or Web VNC |
| Report generation | Test reports generated in PDF, HTML and JSON (for some applications). Reports are easily customizable and can be automatically generated at the conclusion of each test. |
| Laser safety standard | IEC 60825-1:2014-05 |
| Laser safety classification | Laser Class 1 applies only to modules and their TAs and which may vary from that of platform |
