| Electrical | |
| Sampling speed (sample/s) | 1,000,000 |
| Bandwidth (GHz) | 33 (at 3 dB) |
| Input range (Vppd) | 1.0 (max.) |
| Damage amplitude (Vppd) | 1.7 (max.) |
| Connector type | K(f) (50 Ω) |
| Return loss (dB) | –6.5 (at 32 GHz) |
| RMS noise (mV) | 2.0 / 2.5 (max.) |
| Optical | |
| Unfiltered bandwidth (GHz) | 33 (for 28G optical) |
| Wavelength (nm) | 830 to 1600 (full range model); 1250 to 1600 (SMF model) |
| Return loss (dB) | –24 (full range model); –30 (SMF model) |
| Mask sensitivity (dBm) | (CWDM4 mask, mask margin 0%, hit count 0) –8 (at 850 nm) –10 (at 1310 nm) |
| Damage power (mW) | 8 |
| Connector type | FC/PC (50/125 µm) (full range model); FC/PC (9/125 µm) (SMF model) |
| Clock | |
| Clock input ratio | /2, /4, /8, /16, /32, /64 |
| Trigger jitter (fs) | <290 |
| Sensitivity (mV) | 100 |
| All specifications are typical at 23 °C ± 2 °C unless otherwise specified. | |
| Size (H x W x D) | 103 mm x 442 mm x 300 mm (4.1 in x 17.4 in x 11.8 in) |
| Weight | ≤10 kg (22 lb) |
| Temperature (operating) | 5 °C to 40 °C (41 °F to 104 °F) |
| Temperature (storage) | –20 °C to 70 °C (–4 °F to 158 °F) |
| Relative humidity | 20% to 80% |
| Power a | 100/120 Vac (50/60/400 Hz) 220/240 Vac (50/60 Hz) 60 W typical/80 W max. |
| Access interface | Gigabit Ethernet (RJ45 port) |
| a. Operate with supply voltage fluctuations up to ±10 % of the nominal voltage. | |
