| Insertion lossa—All models at 1310, 1550 and 1650 nm (dB) | 2 |
| Crosstalkb (dB) | 50 –50 |
| Back reflectionb (dB) | –45 |
| Switching timee (ms) | 50 |
| Durability (cycles) | 2.5 billion |
| Fiber type | 9/125 µm singlemode fiber |
| Connector type – Output | MPO-APC (16 fibers populated onto a standard MPO 24 fibers ferrule) |
| Connector type – Input | SC-APC |
| Latching type | Non-latching |
| Supply type | USB 2.0 |
| Operating power consumption | ~1 W |
| a. Measured at 23 °C ± 5 °C, including input and output connectors. b. Measured at 1550 nm. c. With less than 80% relative humidity, non-condensing. d. With less than 95% relative humidity, non-condensing. e. Typical. For 1×256 configuration, switching time can be up to 300 ms. | |
| Chassis size | ½ U, rackmount chassis (19”) |
| Size (H × W × D) | 22 mm × 440 mm × 220 mm (7/8 in × 17 5/16 in × 8 11/16 in) |
| Weight | 1.2 kg (2.6 lb) |
| Temperature | Operatingc: –5 °C to 50 °C (23 °F to 122 °F) Storaged: –40 °C to 70 °C (–40 °F to 158 °F) |
| Optical connector location | Front panel |
| Accessories included | Instruction manual (hard copy) GP-3120: 1U rackmount brackets (kit of 2) Extender brackets to ETSI rack size 1.5 m optical jumper SC-APC to SC-APC with FLEX boots USB cable, 1.8 m, right-angle connector |
