| Optical specifications | |
| Crosstalk (dB)a | –50 |
| Back reflection (dB)a | –45 |
| Switching time (ms)b | 300 |
| Durability (cycles) | 2.5 billion |
| Fiber type | 9/125 μm singlemode fiber |
| Model without internal WDM | |
| Insertion loss at 1550 and 1650 nm (dB)c | 1 |
| Connector type – Input | LC-APC |
| Connector type – Output, 4 and 16 port model | LC-APC |
| Connector type – Output, 32 and 64 port model | MPO-APC (16 fibers populated onto a standard MPO 24-fiber ferrule) |
| Connector type – Output, 96 and 144 port model | MPO-APC (24 fibers populated onto a standard MPO 24-fiber ferrule) |
| Model with internal WDM | |
| Insertion loss at 1550 nm – Line to COM (dB)d | 1 |
| Insertion loss at 1650 nm – C to COM (dB)d | 2 |
| Pass band (nm) | 1260 to 1614 |
| Reflect band (nm) | 1619 to 1670 |
| Connector type – Input (OTDR) | LC-APC |
| Connector type – Input (Line) | MPO-APC (16 fibers populated onto a standard MPO 24-fiber ferrule) |
| Connector type – Output (COM), 32 port model | MPO-APC (16 fibers populated onto a standard MPO 24-fiber ferrule) |
| Electrical specifications | |
| Latching type | Non-latching |
| Dual feed power supply | –48VDC 2A (ordering option: external AC-DC adapter for AC operation) |
| Operating power consumption | ~1 W |
| a. Measured at 1650 nm. b. Excluding network latency. c. Measured at 23 °C ± 5 °C, not including input and output connectors for LC/APC models. For MPO models, 1.5 dB (typical). d. Measured at 23 °C ± 5 °C, not including input and output of MPO connectors. | |
| Chassis size | ½ U, rackmount chassis (19”) |
| Size (H × W × D) | 22 mm (½ U) × 440 mm × 220 mm (7/8 in × 17 5/16 in × 8 11/16 in) |
| Weight | 1.4 kg (3.1 lb) |
| Operating temperaturea | –10 °C to 55 °C (14 °F to 131 °F) |
| Storage temperatureb | –40 °C to 70 °C (–40 °F to 158 °F) |
| Optical connector location | Front panel |
| Wired network interfaces | 2 × 10/100/1000 Base-T Ethernet IP-V4 and V6 (network and management interfaces); 1 × SFP (network interface) |
| Accessories included | Instruction manual (hard copy); ½ U rackmount brackets (19” or ETSI) (kit of 2) |
| Regulatory | China RoHS; WEEE Recycling; EMC/EMI: ETSI/EN 300 386; Electrical safety: IEC/EN 61010-1, USA/UL 61010-1, CSA/UL 61010-1; NEBS: GR-1089, GR-63, Verizon VZ.NEBS.TE.NPI.2004.015, Verizon VZ.TPR.9305, ATIS-0600319.2014 section 10.1; ETSI/IEC standards: EN 300 019 (Environmental condition Class 3.3 for telecommunication equipment in cabinets for temperatures up to 55 °C), IEC 60068, IEC 300753, IEC 300386 |
| a. With less than 80% relative humidity, non-condensing. b. With less than 95% relative humidity, non-condensing. | |
