| Configurations | |
| Two-port pass-through | All wavelengths |
| Downstream OLT signal | 1490 nm |
| Downstream RF video signal | 1550 nm |
| Upstream BPON ONT signal | Up to 622 Mbit/s, as per ITU 983 (A, B, C) |
| Upstream EPON and GPON ONT signal | Up to 1.25 Gbit/s, as per ITU 984 and IEEE 802.3ah |
| FTTx mode | |
| Power measurement range — pass zone for continuous data stream at 1310 nm (dBm) | 8 to –40 |
| Power measurement range — pass zone for continuous data stream at 1490 nm (dBm) | 12 to –40 |
| Power measurement range — pass zone for continuous data stream at 1550 nm (dBm) | 25 to –40 |
| Burst measurement capability CO to ONT — burst measurement range at 1310 nm (dBm)b | 8 to –30 |
| ORL at 1550 nm (dB)e | 55 |
| Pass-through insertion loss (dB)b | 1.5 |
| Spectral passband at 1310 nm (nm) | 1260 to 1360 |
| Spectral passband at 1490 nm (nm) | 1480 to 1500 |
| Spectral passband at 1550 nm (nm) | 1539 to 1565 |
| Power uncertainty (dB)b, c, d | 0.5 |
| Calibrated wavelengths (nm) | 1310/1490/1550 |
| Threshold sets | 10 configurable threshold sets with threshold naming |
| OPM mode (broadband CW) | |
| Power measurement range at 1310 nm (dBm) | 25 to –40 |
| Power measurement range at 1490 nm (dBm) | 25 to –40 |
| Power measurement range at 1550 nm (dBm) | 25 to –40 |
| ORL at 1550 nm (dB)e | 55 |
| Power uncertainty (dB)b, c, d | 0.5 |
| Calibrated wavelengths (nm) | 1310/1490/1550 |
| a. At room temperature. b. Typical. c. Around –7 dBm, CW. d. At calibrated wavelengths. e. For APC connectors. f. Without batteries. g. Excluding connector wear. | |
| Size (H × W × D) | 195 mm × 100 mm × 57 mm (7 11/16 in × 4 in × 2 1/4 in) |
| Weightf | 0.4 kg (0.9 lb) |
| Operating temperature | –10 °C to 50 °C (14 °F to 122 °F) |
| Storage temperaturef | –40 °C to 70 °C (–40 °F to 158 °F) |
| Relative humidity | 0% to 95% non-condensing |
| Autonomy (hours)b — FTTx mode (burst) | 35 |
| Autonomy (hours)b — OPM mode (CW) | 80 |
| Number of ports | 2 |
| Calibration interval (years)g | 3 |
| Warranty (year) | 1 |
| Standard accessories | Quick reference guide, USB cable, wrist strap, protective cover for optical ports |
| Laser safety | 21 CFR 1040.10 and IEC 60825-1:2007, Class 3R with VFL option |
| a. At room temperature. b. Typical. c. Around –7 dBm, CW. d. At calibrated wavelengths. e. For APC connectors. f. Without batteries. g. Excluding connector wear. | |
