| Model | MPC-103 MPC-103X |
| Wavelengths (nm) | 850, 980, 1300, 1310, 1490, 1550, 1625 |
| Range (dBm) | MPC-103: –60 to 10 MPC-103X: –45 to 23 |
| Uncertainty (dB)b | ±0.5 |
| Resolution (dB) | 0.01 |
| a. Typical. b. At 23 °C, 1550 nm, –20 dBm, for CW signals and using singlemode fibers. c. Software compatible with Samsung Galaxy Note® 4 & 5, Samsung Galaxy S® 3, 4, 5, 6 & 7, Google Nexus 5X, Apple iPhone 6S Plus & 7 and Apple iPad Air 2 devices. Other models are not guaranteed to be fully compatible. Download our free MPC-100 app on Google Play and App Store. d. Not available on Android tablets. | |
| Adapter type | Standard: universal 2.50 mm Optional: universal adapter for 1.25 mm |
| Bluetooth | 4.0 BLE (4 m) |
| Smart device OS compatibilityc, d | Android 5.1 and above, iOS 9.3 and above |
| Battery autonomy | 3 h continuous |
| Storage | 100 measurements internal (virtually unlimited via smart device and cloud) |
| Size (H x W x D) | 32 mm x 102 mm x 24 mm (1 1/4 in x 4 in x 15/16 in) |
| Weight | 70 g (0.15 lb) |
