| Wavelength (nm) (b) | 1310 ± 20/1550 ± 20/1650 ± 15 |
| Live wavelength (nm) | 1650, Isolation: 50 dB from 1265 nm to 1617 nm |
| Dynamic range (dB) (c) | 42/40/39 |
| Event dead zone (m) (d) | 0.5 |
| Attenuation dead zone (m) (d) | 2.5 |
| Distance range (km) | 0.65 to 200 |
| PON dead zone (m) (e) | 30 |
| Pulse width (ns) | 3 to 20 000 |
| Linearity (dB/dB) | ±0.03 |
| Loss resolution (dB) | 0.001 |
| Sampling resolution (m) | 0.04 to 5 |
| Sampling points | Up to 256 000 |
| Distance uncertainty (m) (f) | ±(0.75 + 0.0025% × distance + sampling resolution) |
| Reflectance accuracy (dB) (b) | ±2 |
| IN-LINE POWER CHECKER (b, h) | |
| Power range (dBm) | –60 to 23 |
| Power uncertainty (dB) (i, j) | ±0.5 |
| Calibrated wavelengths (nm) | 1310, 1490, 1550, 1625, 1650 |
| Selectable wavelengths (nm) | 1310, 1490, 1550, 1577, 1625, 1650 |
| Tone detection | CW, 270 Hz, 330 Hz, 1 kHz, 2 kHz, 1 kHz + Blink, 2 kHz + Blink |
| IN-LINE SOURCE | |
| Output power (dBm) (k) | –3 |
| Modulation | CW, 270 Hz, 330 Hz, 1 kHz, 2 kHz, 1 kHz + Blink, 2 kHz + Blink |
| VISUAL FAULT LOCATOR (VFL) | |
| Laser | 650 nm ± 10 nm |
| CW/Modulate | 1 Hz |
| Typical Pout in 62.5/125 µm | > 0 dBm (1 mW) |
| Laser safety | Class 2 |
| Laser safety standard | IEC/CEI 60825-1:2014 (complies with FDA 1040.10 and IEC 60825-1:2014-05) |
| IN-LINE PON POWER METER WITH OPM2 IN OPTION a, b | |
| Power range (dBm) | –60 to 23 |
| PON power meter (nm) | Two channels: 1490/1550 and 1490/1577 |
| Power uncertainty (dB) (c, d) | ±0.5 |
| Calibrated wavelengths (nm) | 1310, 1490, 1550, 1625, 1650 |
| Selectable wavelengths (nm) | 1310, 1490, 1550, 1577, 1625, 1650, 1490/1550, 1490/1577 |
| a. All specifications valid at 23 °C ± 2 °C with an FC/APC connector, unless otherwise specified. b. Typical. c. Typical dynamic range with longest pulse and three-minute averaging at SNR = 1. d. Typical, for reflectance from –55 dB, using a 3-ns pulse. e. Non-reflective FUT, non-reflective splitter, 13-dB loss, 100-ns pulse, typical value. f. Does not include uncertainty due to fiber index. g. –20 °C to 60 °C (–4 °F to 140 °F) with the battery pack. To preserve optimal battery performance, do not expose to high storage temperatures for extended periods of time. h. Specifications valid when OTDR not in operation or in idle mode. i. At calibrated wavelengths. j. Requires a good entry connector’s health. k. Typical output power is given at 1550 nm. a. Typical. b. Specifications valid when OTDR not in operation or in idle mode. c. At calibrated wavelengths. d. Requires a good entry connector’s health. | |
| Size (H × W × D) | 171 mm × 93 mm × 48 mm (6 3/4 in × 3 11/16 in × 1 7/8 in) |
| Weight (with battery) | 0.5 kg (1.1 lb) |
| Display | 4 in (101.6 mm) touchscreen, 800 × 480 TFT, portrait and landscape view |
| Interfaces | One USB-C port |
| Storage | 10 000 OTDR traces, typical |
| Connectivity | Bluetooth®, Wi-Fi and USB-C |
| Results format | PDF report on the unit .sor trace as per Telcordia (Bellcore), .trcx |
| Battery | Rechargeable lithium-polymer battery, USB-C charging port connector |
| Battery autonomy | >10 hours of operation as per Telcordia (Bellcore) TR-NWT-001138 |
| Temperature (operating) | –10 °C to 45 °C (14 °F to 113 °F) |
| Temperature (storage) (g) | –40 °C to 70 °C (–40 °F to 158 °F) |
| Relative humidity | < 93 % non-condensing |
| Data management | FastReporter, EXFO Exchange |
| Adapters | Multiple changeable adapters to fit any optical connectors: SC, FC, LC, and more |
| Warranty (year) | 1 |
| g. –20 °C to 60 °C (–4 °F to 140 °F) with the battery pack. To preserve optimal battery performance, do not expose to high storage temperatures for extended periods of time. | |
