| Wavelength (nm) (b) | 1310 ± 30/1550 ± 30 |
| Dynamic range (dB) (c) | 35/33 |
| Event dead zone (m) (d) | 0.8 |
| Attenuation dead zone (m) (d) | 3.5 |
| Distance range (km) | 0.65 to 200 |
| PON dead zone (m) (e) | 35 |
| Pulse width (ns) | 3 to 20 000 |
| Linearity (dB/dB) | ±0.05 |
| Loss resolution (dB) | 0.001 |
| Sampling resolution (m) | 0.04 to 5 |
| Sampling points | Up to 256 000 |
| Distance uncertainty (m) (f) | ±(0.75 + 0.0025% × distance + sampling resolution) |
| Reflectance accuracy (dB) (b) | ±2 |
| In-line power checker (b,h) — Power range (dBm) | –60 to 23 |
| In-line power checker — Power uncertainty (dB) (i,j) | ±0.5 |
| In-line power checker — Calibrated wavelengths (nm) | 1310, 1490, 1550, 1625, 1650 |
| In-line power checker — Selectable wavelengths (nm) | 1310, 1490, 1550, 1577, 1625, 1650 |
| In-line power checker — Tone detection | CW, 270 Hz, 330 Hz, 1 kHz, 2 kHz, 1 kHz + Blink, 2 kHz + Blink |
| In-line source — Output power (dBm) (k) | –7 |
| In-line source — Modulation | CW, 270 Hz, 330 Hz, 1 kHz, 2 kHz, 1 kHz + Blink, 2 kHz + Blink |
| Visual fault locator (VFL) — Laser | 650 nm ± 10 nm |
| Visual fault locator (VFL) — CW/Modulate | 1 Hz |
| Visual fault locator (VFL) — Typical Pout in 62.5/125 µm | > –1.5 dBm (0.7 mW) |
| Visual fault locator (VFL) — Laser safety | Class 2 |
| Laser safety | IEC/CEI 60825-1:2014 (complies with FDA 1040.10 and IEC 60825-1:2014) |
| Notes: a All specifications valid at 23 °C ± 2 °C with an FC/APC connector, unless otherwise specified. b Typical. c Typical dynamic range with longest pulse and three-minute averaging at SNR = 1. d Typical, for reflectance from –55 dB, using a 3-ns pulse. e Non-reflective FUT, non-reflective splitter, 13-dB loss, 100-ns pulse, typical value. f Does not include uncertainty due to fiber index. g –20 °C to 60 °C (–4 °F to 140 °F) with the battery pack. To preserve optimal battery performance, do not expose to high storage temperatures for extended periods of time. h Specifications valid when OTDR not in operation or in idle mode. i At calibrated wavelengths. j Requires a good entry connector’s health. k Typical output power is given at 1550 nm. | |
| Size (H × W × D) | 171 mm × 93 mm × 48 mm (6 3/4 in × 3 11/16 in × 1 7/8 in) |
| Weight (with battery) | 0.5 kg (1.1 lb) |
| Display | 4 in (101.6 mm) touchscreen, 800 × 480 TFT, portrait and landscape view |
| Interfaces | One USB-C port |
| Storage | 10 000 OTDR traces, typical |
| Connectivity | Bluetooth®, Wi-Fi and USB-C |
| Results format | PDF report on the unit; .sor trace as per Telcordia (Bellcore), .trcx |
| Battery | Rechargeable lithium-polymer battery, USB-C charging port connector |
| Battery autonomy | >10 hours of operation as per Telcordia (Bellcore) TR-NWT-001138 |
| Operating temperature | –10 °C to 45 °C (14 °F to 113 °F) |
| Storage temperature g | –40 °C to 70 °C (–40 °F to 158 °F) |
| Relative humidity | < 93 % non-condensing |
| Data management | FastReporter 3, EXFO Exchange |
| Adapters | Multiple changeable adapters to fit any optical connectors: SC, FC, LC, and more |
| Warranty (year) | 1 |
| Notes: g –20 °C to 60 °C (–4 °F to 140 °F) with the battery pack. To preserve optimal battery performance, do not expose to high storage temperatures for extended periods of time. | |
