FTBx-735C - metro/PON FTTx/MDU OTDR

Overview
  • Discontinued date: 5/1/2025
  • End-of-service and support date: 5/1/2030
  • End-of-calibration date: 5/1/2030
High-resolution OTDR designed for metro network testing and splitter characterization in PON FTTx applications.

Key features

  • Dynamic range of up to 42 dB, event dead zone 0.5m and atten. zone of 2.5m
  • Singlemode port for in-service troubleshooting with in-line 1490/1550 nm power meter
  • EXFO Connect-compatible: automated asset management; data goes through the cloud and into a dynamic database
  • iOLM-ready: one-touch multiple acquisitions, with clear go/no-go results presented in a straightforward visual format

Applications

  • FTTx PON
  • Manufacturing automation
  • Metro

Specifications

Technical specifications
Calibrated wavelengths 1310 / 1490 / 1550 / 1625
Distance Range Max 400
Distance Range Min (dB) 0.1
Dynamic range (dB) 42 dB
Exchange compatibility Yes
iOLM-ready Yes
Module Number of Slots 1 slot
Product type Module
Recalibration Month Interval 12
Test Type Fault location / Fiber characterization / Fiber length / Loss / ORL / Optical power
Full specifications

Resources

Spec sheet

FTBx-735C metro/PON FTTx/MDU OTDR
User manual

iOLM
All resources

Description

The FTBx-735C has been designed to test FTTH/PON networks and longer links in the metro range. This OTDR has 42 dB of dynamic range to test up to 150 km of optical fiber. The PON-optimized performances of the FTBx-735C enable it to fully characterize links up to a 1:128 FTTH/PON splitter ratio.

With its high dynamic range, the FTBx-735C empowers technicians to test optical fibers with greater speed and accuracy.

The FTBx-735C advantage

  • The industry’s highest resolution for PON testing and the shortest PON dead zone to detect more problems closer to the splitter.
  • High resolution for maximum fiber characterization on long links up to 150 km. Ideal to support bidirectional testing.
